1600kg Small Excavators for Sale Mini Excavators Yc16-9
1600Kg Small Excavators For Sale Mini Excavators YC16-9 Product Description equipped with adjustable chassis to improve working stability wide-open engine cover for higher maintainabilityoperator-oriented design enables comfortable operatingMain Parameter Transportation dimension Overall length of ......
Send Inquiry
Product Description
1600Kg Small Excavators For Sale Mini Excavators YC16-9
Product Description
- equipped with adjustable chassis to improve working stability
- wide-open engine cover for higher maintainability
- operator-oriented design enables comfortable operating
Main Parameter
| Transportation dimension | ||
| Overall length of transportation | 3590mm | |
| Overall width | 1014mm | |
| Overall height | 2280mm | |
| Other Parameter | ||
| Width of undercarriage | 990mm | |
| Length of track | 1565mm | |
| Width of track | 230mm | |
| Height between undercarriage and ground | 190mm | |
| Height between platform and ground | 470mm | |
| Platform tail turning radius | 1140mm | |
| Track gauge | 760mm | |
| Fuel tank capacity | 20L | |
| Hydraulic oil tank capacity | 22L | |
| Max. digging height | 2945mm |
| Max. digging depth | 1885mm |
| Max. digging radius | 3645mm |
| Max. digging radius on ground level | 3540mm |
| Max. dumping height | 1965mm |
| Min. slewing radius | 1720mm |
| Max. vertical digging depth | 1215mm |
| Gradeability | 30° |
| Max. digging force of arm | 12.5kN |
| Max. digging force of bucket | 8kN |
| Traveling speed | 2km/h |
| Max. hauling force | kN |
| Slewing speed of platform | 9~11rpm |
| Engine model | Laidong 3TE20A |
| Engine power | 14.8kW/2200rpm |
Product Show
