Forload 1.6tons New and Used Hydraulic Mini Crawler Excavator with Yanmar/Perkins Euro5 EPA4 Engine
FORLOAD brand mini crawler hydraulic excavator1-Streamlined appearance design, low fuel consumption and wide operating range.2-Have CE certificate meet European market request.3-Much suitable for loosing soil of vegetable greenhouse, campus greening of municipal departments, digging the hole for tre......
Send Inquiry
Product Description
FORLOAD brand mini crawler hydraulic excavator
1-Streamlined appearance design, low fuel consumption and wide operating range.
2-Have CE certificate meet European market request.
3-Much suitable for loosing soil of vegetable greenhouse, campus greening of municipal departments, digging the hole for tree, planting of fruit-land nurseries, concrete pavement crushing, sand-gravel material mixing, construction working in narrow place and so on.
4-Optional hydraulic quick hitch, hammer, ripper, auger, thumb, different size buckets.
1-Streamlined appearance design, low fuel consumption and wide operating range.
2-Have CE certificate meet European market request.
3-Much suitable for loosing soil of vegetable greenhouse, campus greening of municipal departments, digging the hole for tree, planting of fruit-land nurseries, concrete pavement crushing, sand-gravel material mixing, construction working in narrow place and so on.
4-Optional hydraulic quick hitch, hammer, ripper, auger, thumb, different size buckets.
| Brand | FORLOAD |
| Model | TBE16B |
| Operating mode | Mechanical lever |
| Operating weight | 1600 kg |
| Bucket capacity | 0.05 cbm |
| Bucket width | 480mm (any size can be customized) |
| Engine | LAIDONG 380B, 13.6kw/2200r/min |
| Pump | FUTAI 309 |
| Valve | HUSCO(USA) |
| Walking motor | SANYANG (China) |
| Rotary motor | EASTON (USA) |
| Cylinder | Three-cylinder, Water cooling |
| Walking speed | 3.5km/h |
| Track type | Rubber Track |
| Closed cab | No |
| Climb ability | 35º |
| Bucket digging force | 14.9 kn |
| Arm digging force | 13.2 kn |
| Physical Size | |
| Total (length*width*height) | 3635x980x2100 mm |
| Track length*width | 1450mm*230mm |
| Platform ground distance | 450 mm |
| Chassis width | 1060 mm |
| Working Range | |
| Max. digging depth | 1950 mm |
| Max. digging height | 3300 mm |
| Max. digging radius | 3500 mm |
| Min. radius of gyration | 1640 mm |
