Hot Sale Asphalt Concrete Paver RP601 with Good Service
Hot sale asphalt concrete paver RP601 with good servicepaver is the first set of full hydraulic medium 3 series wheel asphalt concrete paver launched by Xugong Group; the whole machine adopts full hydraulic drive and electro-hydraulic automatic control, whose technology is advanced and performance i......
Send Inquiry
Product Description
Hot sale asphalt concrete paver RP601 with good service
paver is the first set of full hydraulic medium 3 series wheel asphalt concrete paver launched by Xugong Group; the whole machine adopts full hydraulic drive and electro-hydraulic automatic control, whose technology is advanced and performance is reliable; it is widely applied to paving construction in a wide range, including side pavement, bike path, urban roads and small roads. Its paving width ranges from 2.5m to 6.0m which is stepless adjustable, so it is especially suitable for maintenance construction of grade highways.
paver is the first set of full hydraulic medium 3 series wheel asphalt concrete paver launched by Xugong Group; the whole machine adopts full hydraulic drive and electro-hydraulic automatic control, whose technology is advanced and performance is reliable; it is widely applied to paving construction in a wide range, including side pavement, bike path, urban roads and small roads. Its paving width ranges from 2.5m to 6.0m which is stepless adjustable, so it is especially suitable for maintenance construction of grade highways.
| Item | Unit | RP603 |
|---|---|---|
| Basic paving width | m | 2.5 |
| Max. paving width | m | 6 |
| Max. paving thickness | mm | 380 |
| Paving speed | m/min | 0~14 |
| Travel speed | km/h | 0~3.0 |
| Theoretical productivity | t/h | 400 |
| Hopper capacity | t | 13 |
| Gradeability | % | 20 |
| Pavement evenness | mm/3m | 3 |
| Cross slope error | % | ±0.03 |
| Crown adjustment range | % | 0~3 |
| Diesel engine model | ||
| Diesel engine power | kw | 128 |
| Diesel engine speed | r/min | 2300 |
| Diesel oil tank capacity | L | 230 |
| Overall weight | t | 15.8~21.5 |
| Dimension | mm | 6230×2500×3855 |
| Vibration frequency | Hz | / |
| Screed heating mode | Electrical heating | |
| Material level control mode | Automatic Control by Ultrasonic Sensor | |
| Automatic Leveling Control | Simulation control |
| Item | Unit |
|---|---|
| Screed model | 475(RP602) |
| Type | Vibration, electrical heating |
| Stretch mode | Hydraulic stretch |
| Width range | 2.5-6.0m |
| Vibrating tamper rotate speed | 0-1500r/min |
| Vibration frequency | 4mm |
| Items | Unit | Parameters |
|---|---|---|
| Screed model | / | EV35Q |
| Type | / | Gas heating, vibration |
| Extension | / | Hydraulic |
| Width | m | 2.0-4.5 |
| Vibrator speed | Hz | 0-42 |
