Why Is Cross-Interference Important When Choosing Gas Analyzers?

2026-10-21

An instrument engineer commissions a Gas Analyzers system for a biogas plant. The analyzer is calibrated with a certified methane standard and reads 60 percent CH₄ in the calibration gas. At the site, the same analyzer reads 72 percent CH₄ in the digester gas. The plant operator suspects the analyzer is faulty. The engineer investigates and finds that the biogas contains 35 percent carbon dioxide. The NDIR sensor in the analyzer is responding to the CO₂ as well as the CH₄. This is cross-interference. The analyzer is not faulty. It is being used in a background gas that it was not designed to handle. This guide explains why cross-interference matters when choosing gas analyzers and how to specify the right technology for the background gas.

1. What Is Cross-Interference and How Does It Occur?

Cross-interference is the response of a Gas Analyzers sensor to a gas other than the target gas. It occurs because the sensor's detection mechanism is not perfectly selective. There are three mechanisms. The first is spectral overlap in optical sensors. An NDIR sensor measures the absorption of infrared light at a specific wavelength. If another gas absorbs at the same wavelength, it will contribute to the reading. The second is electrochemical cross-sensitivity. An electrochemical sensor measures the current produced by the oxidation or reduction of the target gas. Other gases that react at the same electrode potential will also produce a current. The third is catalytic poisoning or inhibition. A catalytic bead sensor measures the heat generated by the combustion of the target gas. Other gases can inhibit the catalyst or burn at a different rate, which changes the reading. The table below shows common cross-interference pairs.

Target gas	Interfering gas	Sensor type	Typical interference level
CH₄	CO₂	NDIR	5 – 15% of reading
CO	H₂	Electrochemical	10 – 30% of reading
H₂S	SO₂	Electrochemical	5 – 10% of reading
O₂	CO	Electrochemical	1 – 3% of reading
CO₂	H₂O vapor	NDIR	2 – 8% of reading

In our factory, we manufacture Gas Analyzers with NDIR, electrochemical, and catalytic sensors. We provide a cross-interference table for each sensor type so that the customer can evaluate the risk for their specific background gas. Beijing Zetron Technology Co., Ltd. has been manufacturing gas analyzers for over 12 years.

2. How Does the Background Gas Composition Affect Sensor Selection?

The background gas composition is the most important factor in sensor selection. A sensor that performs well in clean air may fail in a background gas that contains interfering components. The engineer must analyze the background gas and select a sensor that is not sensitive to the interfering components, or apply a correction. The table below shows the recommended sensor technology for different background gases.

Background gas	Target gas	Recommended sensor	Sensor to avoid
Biogas (CH₄ + CO₂)	CH₄	NDIR with dual wavelength	Single wavelength NDIR
Flue gas (CO₂ + H₂O + SO₂)	CO	Electrochemical with filter	Catalytic bead
Natural gas (CH₄ + C₂H₆)	CH₄	NDIR or catalytic	Electrochemical
Hydrogen-rich atmosphere	CO	Electrochemical with H₂ filter	Standard electrochemical
Solvent vapor (VOC)	CO₂	NDIR with humidity compensation	NDIR without compensation

Instrument engineer's note: The background gas analysis should be performed before the analyzer is specified. In our factory, we ask the customer to provide the background gas composition, including the concentration of all major components and the expected range of variation. We then select the sensor technology and the filter that minimize the cross-interference. If the interference cannot be eliminated, we provide a correction algorithm that uses a second sensor to measure the interfering gas and subtract its contribution from the reading. Beijing Zetron Technology Co., Ltd. provides this dual-sensor solution for biogas and flue gas applications.

3. How Can Cross-Interference Be Corrected in the Field?

Cross-interference can be corrected in the field using three methods. The first is a scrubber or filter. A chemical filter is placed in the sample line to remove the interfering gas before it reaches the sensor. For example, a filter containing activated carbon can remove H₂S from a gas stream before it reaches a CO sensor. The second is a dual-sensor configuration. Two sensors are used: one for the target gas and one for the interfering gas. The analyzer's microprocessor subtracts the interfering gas contribution from the target gas reading. The third is a compensation algorithm. The analyzer uses the known relationship between the interfering gas concentration and the sensor response to correct the reading. The table below shows the correction methods and their applicability.

Correction method	Principle	Best for	Limitation
Scrubber / filter	Removes interfering gas	Known interfering gas, low concentration	Filter must be replaced periodically
Dual-sensor	Measures and subtracts	Variable interfering gas concentration	Higher cost, more complex
Compensation algorithm	Software correction	Stable interfering gas ratio	Requires calibration data

In our factory, we provide all three correction methods. The scrubber is the simplest and least expensive. The dual-sensor is the most accurate. The compensation algorithm is the most flexible. Beijing Zetron Technology Co., Ltd. provides a cross-interference correction service that includes the background gas analysis, the sensor selection, and the calibration of the correction algorithm.

4. What Should Be Included in a Cross-Interference Test Report?

A cross-interference test report should be included with every Gas Analyzers quotation. The report should list the target gas, the interfering gases, the sensor type, the interference level, and the correction method. The table below shows the structure of a typical report.

Report section	Content	Example
Target gas	Gas name and concentration range	CH₄, 0 – 100%
Background gas	Composition and concentration	CO₂ 35%, H₂O 5%, H₂S 0.1%
Sensor type	Technology and model	NDIR, dual wavelength
Interference level	Response to each interfering gas	CO₂: +8% of reading
Correction method	Scrubber, dual-sensor, or algorithm	Dual-sensor with CO₂ channel
Residual error	Error after correction	< 2% of reading

In our factory, we perform the cross-interference test on every analyzer model before shipment. The test uses certified gas mixtures that simulate the customer's background gas. The report is included in the shipment documentation. Beijing Zetron Technology Co., Ltd. also provides a field verification kit that the customer can use to check the analyzer performance after installation.

Frequently Asked Questions About Cross-Interference in Gas Analyzers

Question 1: How do I know if my gas analyzer is affected by cross-interference?

Answer: The most common sign of cross-interference is a reading that does not match the expected value based on the process conditions. For example, a biogas analyzer that reads 72 percent CH₄ when the process should produce 60 percent CH₄ is likely affected by CO₂ interference. Another sign is a reading that changes when the background gas composition changes, even though the target gas concentration is stable. To confirm cross-interference, you can perform a test with a gas mixture that contains the target gas and the suspected interfering gas. If the reading is higher or lower than the target gas concentration alone, cross-interference is present. In our factory, we provide a cross-interference test kit that includes the gas mixtures and the test procedure.

Question 2: Can cross-interference be eliminated entirely?

Answer: Cross-interference cannot be eliminated entirely, but it can be reduced to an acceptable level. The most effective method is to select a sensor technology that is not sensitive to the interfering gas. For example, a dual-wavelength NDIR sensor can distinguish between CH₄ and CO₂ because the two gases absorb at different wavelengths. If a suitable sensor is not available, a scrubber or a dual-sensor configuration can reduce the interference to less than 2 percent of reading. In our factory, we specify the residual error after correction in the cross-interference test report. For most industrial applications, a residual error of less than 2 percent is acceptable. For high-accuracy applications, we recommend a dual-sensor configuration with a residual error of less than 1 percent.

Question 3: How often should the cross-interference correction be verified in the field?

Answer: The cross-interference correction should be verified every 3 to 6 months, depending on the stability of the background gas. If the background gas composition is stable, an annual verification is sufficient. If the background gas composition varies, a quarterly verification is recommended. The verification involves introducing a known concentration of the interfering gas and checking that the analyzer reading does not change. In our factory, we provide a field verification kit that includes a small cylinder of the interfering gas and a regulator. The kit also includes a verification procedure and a log sheet. Beijing Zetron Technology Co., Ltd. recommends that the verification be performed by a trained technician and that the results be recorded in the maintenance log.

Summary for Instrument Engineers and Safety Managers

Cross-interference is a critical factor in Gas Analyzers selection. It occurs when the sensor responds to a gas other than the target gas. The background gas composition determines the severity of the interference. The engineer should analyze the background gas, select a sensor technology that minimizes the interference, and apply a correction method if necessary. The cross-interference test report should be included in the analyzer documentation. The correction should be verified periodically in the field. By addressing cross-interference at the selection stage, engineers can avoid false alarms, missed alarms, and inaccurate process control. Beijing Zetron Technology Co., Ltd. has been manufacturing gas analyzers for over 12 years and provides full cross-interference analysis and correction support for our customers.

Beijing Zetron Technology Co., Ltd. manufactures Gas Analyzers with NDIR, electrochemical, and catalytic sensors, dual-wavelength options, and scrubber filters. We provide cross-interference test reports, field verification kits, and correction algorithm calibration for all of our products.

Need help selecting a gas analyzer with low cross-interference for your application? Contact Beijing Zetron Technology Co., Ltd. for a free consultation. We will analyze your background gas and recommend the optimal sensor technology and correction method.
