500L, 750L, 1000L, 1500L , 2000L Twin Shaft Concrete Mixer
Twin shaft Concrete MixerAll Sizes of twin shaft concrete mxer:We have JS500, JS750, JS1000, JS1500, JS2000, JS3000, compulsory concrete cement mixer with two horizontal shaft.Advantages of JS series Twin shaft concrete mixer:JS Series compulsory concrete cement mixer with two horizontal shaft can m......
Send Inquiry
Product Description
Twin shaft Concrete Mixer
All Sizes of twin shaft concrete mxer:
We have JS500, JS750, JS1000, JS1500, JS2000, JS3000, compulsory concrete cement mixer with two horizontal shaft.
Advantages of JS series Twin shaft concrete mixer:
JS Series compulsory concrete cement mixer with two horizontal shaft can mix the plastic and half-dry hard concrete, fluid concrete and light aggregate concrete.
1. Working condition: Road, Bridge & Precast product for factory, work independently or be used with correspond batching machine as a mini-type concrete plant.
2. Discharge system: Hydraulic & manual mode, drive reposefully and low noise.
3. Inside Mixer: Liner and mixer blade adopts high rigidity wear resistant steel (long service life).
Application of JS series Twin shaft concrete mixer:
Based on the advantages of driving steady and convenient installation, this key concrete equipment is widely used in the small and medium-sized construction.
Our JS Series compulsory concrete cement mixer with two horizontal shaft is mainly used in concrete batching plant; JS500 for HZS25, JS750 for HZS35, JS1000 for HZS50 and HZS60, JS1500 for HZS75 and JS90, JS2000 for HZS120, JS3000 for HZS180, they can also be used alone to produce concrete.
All Sizes of twin shaft concrete mxer:
We have JS500, JS750, JS1000, JS1500, JS2000, JS3000, compulsory concrete cement mixer with two horizontal shaft.
Advantages of JS series Twin shaft concrete mixer:
JS Series compulsory concrete cement mixer with two horizontal shaft can mix the plastic and half-dry hard concrete, fluid concrete and light aggregate concrete.
1. Working condition: Road, Bridge & Precast product for factory, work independently or be used with correspond batching machine as a mini-type concrete plant.
2. Discharge system: Hydraulic & manual mode, drive reposefully and low noise.
3. Inside Mixer: Liner and mixer blade adopts high rigidity wear resistant steel (long service life).
Application of JS series Twin shaft concrete mixer:
Based on the advantages of driving steady and convenient installation, this key concrete equipment is widely used in the small and medium-sized construction.
Our JS Series compulsory concrete cement mixer with two horizontal shaft is mainly used in concrete batching plant; JS500 for HZS25, JS750 for HZS35, JS1000 for HZS50 and HZS60, JS1500 for HZS75 and JS90, JS2000 for HZS120, JS3000 for HZS180, they can also be used alone to produce concrete.
| Model parameter | JS500 | JS750 | JS1000 | JS1500 | JS2000 | JS3000 | JS4000 | |
| Discharge vol.(L) | 500 | 750 | 1000 | 1500 | 2000 | 3000 | 4000 | |
| Charging vo.(L) | 800 | 1200 | 1600 | 2400 | 3200 | 4800 | 6400 | |
| Output capacity(m³) | 25 | 35 | 50-60 | 75-90 | 120 | 180 | 240 | |
| Aggregate size(mm) | 80 | |||||||
| Working circle(s) | 60 | |||||||
| Discharge height(m) | 1.5-4.1 adjustable | |||||||
| Mixing blade | Speed | 31r/min | 19.5r/min | 21r/min | ||||
| Quantity | 2x7 | 2x8 | 2x10 | |||||
| Mixing motor | 18.5kw | 30kw | 2x18.5kw | 2x22kw | 2x37kw | 2x55kw | 2x75kw | |
| Lifting motor | 5.5kw | 7.5kw | 11kw | 18.5kw | - | - | - | |
| Pump motor | 0.75kw | 1.1kw | 3kw | 3kw | - | - | - | |
| Weight(kg) | 4000 | 5500 | 8700 | 9880 | 10960 | 11130 | 13500 | |
| Dimension(LxWxH) mm | 3030x2300x2680 | 4550x2250x2450 | 4640x2250x2250 | 5058x2250x2440 | 3810x2480x1710 | 4220x2620x1910 | 4450x3050x2380 | |
