Hbt60-11RS High Pressure Diesel Concrete Injection Pump

Product Description

HBT60-11RS high pressure diesel concrete injection pump

1. Description:
In order to meet the demand of open country and other no power supply constructions, we research and developed the diesel engine concrete pump. Our concrete pump is set of mechanical, electrical and hydraulic technology as one, with reliable performance of smooth operation and strong pumping capability. The diesel engine is with advanced high quality, low emission, low fuel consumption, meet the advanced standard. Reliability and stability is guaranteed by automatic engine regulation.

2. Application:
Convey floor heating lightweight foamed cement, mortar, fine aggregate concrete.
Convey greening soil in ecological environment construction.
Convey all kinds of engineering construction in the plain concrete, fiber concrete.

3. Features:
Intelligent power control system to regulate the engine speed automatically, for smooth and efficient operation
Plunger pump with constant power, to ensure the efficiency of main engine
High delivery pressure for demand of high-rise and long distance projects
Good sealing S-valve, installed with floating wear resistant ring
High-quality wear resistant alloy components for long service-life
Air cooling system, without dependence of external water
PLC system to ensure best control performance
With re-pumping function to smooth construction of better accessibility
Equipped with wireless remote controller, easy to operate

4. Technical parameters of concrete pump equipment:

Model No.	HBT60-11RS
Max. theoretical concrete output (m³/h)	27/55
Max. theoretical concrete pumping pressure (Mpa)	4.7/9.3
Theoretical vertical conveying height (m)	130
Theoretical level transmission distance (m )	350
Max. Aggregate particles (mm)	40-45
Slump (cm)	12-23
Concrete tube conveying diameter (mm)	133/150
Hydraulic oil tank volume (L)	460
Hopper volume (m³)	0.6
Filling height (mm)	1400
Diesel engine power (kw)	112
Diesel fuel tank volume	120L
Machine Overall dimension (L×W×H) (mm)	510021602600
Total weight (kg)	6000

5. Packing: In Nude, One unit/20GP
Delivery time: Usually in 10 working days for the concrete pump for sale

6. Our Advantages and services:
Factory directly supply.
Professional sales team and experienced workers.
Competitive price according to good raw material purchasing ability, and high work efficiency
Best manufacturer in China.
Good after-sales service
Spare Parts Supply Timely

For more information about concrete pumping machine, please feel free to contact us.
