Product Description

Liugong Hold Trailer Concrete Pump HBT60-18-132S

1. 60 cbm output
2. Shangchai, Deutz, Perkins diesel engine
3. 132KW power

Power system
World top brand caterpillar, Deutz, Perkins diesel engine and electrical motor, strong power and low defect.
Control system PLC program controller, well receive or send the signal expediently. It connects with the computer closely. When there is abnormal, it will recover the the original process.
Mixing system is driven by hydraulic motor. The hopper is unique in design, as assure that there is no accumulated material.

The pump is imported from Germany Rexroth, USA VICKERS. Big discharge, high efficiency, long span, and stable function and can run for a long period Lastingly.

No.	Item	Unit	HBT60-18-132S
1	Theory Concrete Output (Low / High Pressure)	m 3 /h	60/40
2	Concrete Pressure (Low / high pressure)	Mpa	11.5/18
3	Hydraulic system pressure	Mpa	32
4	Rotation speed	r/min	1480
5	High / low pressure switch		Yes
6	Distribution valve		S valve
7	Pumping cylinder diameter/ Stroke	mm	200/1800
8	Main oil pump discharge	ml/r	260
9	Motor power	kw	132
10	Voltage/ Frequency	V/Hz	380/50
11	Hydraulic tank volume	L	500
12	Height of adding material	mm	≤1450
13	Hopper volume	m 3	0.7
14	Total mass	kg	5800
15	Concrete slump	mm	80-230
16	Theory vertical pumping height	m	280
17	Theory direction change times Low/High pressure	times/min	18/12
18	Dimension: LXWXH	mm	6400×2480×2350
