Yhzs50 50m3/H Portable Beton Batching Plant
Installation Video of Portable Beton Batching Plant:micfocus.en.made-in-china.comWhy would our clients choose FOCUS Portable beton batching plant? FOCUS MACHINERY boasts an award-wining portable beton batching plant product range with capacity from 25cbm to 75cbm hourly. This series of semi-trailer ......
Send Inquiry
Product Description
Installation Video of Portable Beton Batching Plant:
micfocus.en.made-in-china.com
Why would our clients choose FOCUS Portable beton batching plant?
FOCUS MACHINERY boasts an award-wining portable beton batching plant product range with capacity from 25cbm to 75cbm hourly.
This series of semi-trailer mixing plant adopts semi-pulling structure with running system and equipped with standard coupling pin, hence can be dragged by a tractor at the maximum speed of 40km/h.
As uniquely and compactly designed it is, this portable beton batching plant assembles whole functions of accurate material weighing, efficient aggregate conveying, homogeneous mixing, computer auto-controlling and trailing. It is the ideal concrete plant for projects that require frequent removal from one site to another.
What are the main features of FOCUS portable concrete batching plant?
1. Complete mobile unit:
Unit easily transported on-site as well as from project to project, on-board hydraulic system changes plant from travel mode to full operational within 2-3 hours for this portable beton batching plant.
2. Reliability of mix consistency:
Computer and manual dual control mode can be converted easily by a simple switch, twin-shaft mixer offers this portable beton batching plant a consistent high grade of evenly mixed material, with its good quality mixing blades, paddles, arms and liners.
3. Highly precise dosing of water, cement, fly-ash, additive
Focus portable beton batching plant dosing is realized by three-point suspension sensors, and they are all metered separately.
4. Optimized and modular design
Installation of Mobile Concrete Mixing Plant in Algeria:
micfocus.en.made-in-china.com
Why would our clients choose FOCUS Portable beton batching plant?
FOCUS MACHINERY boasts an award-wining portable beton batching plant product range with capacity from 25cbm to 75cbm hourly.
This series of semi-trailer mixing plant adopts semi-pulling structure with running system and equipped with standard coupling pin, hence can be dragged by a tractor at the maximum speed of 40km/h.
As uniquely and compactly designed it is, this portable beton batching plant assembles whole functions of accurate material weighing, efficient aggregate conveying, homogeneous mixing, computer auto-controlling and trailing. It is the ideal concrete plant for projects that require frequent removal from one site to another.
What are the main features of FOCUS portable concrete batching plant?
1. Complete mobile unit:
Unit easily transported on-site as well as from project to project, on-board hydraulic system changes plant from travel mode to full operational within 2-3 hours for this portable beton batching plant.
2. Reliability of mix consistency:
Computer and manual dual control mode can be converted easily by a simple switch, twin-shaft mixer offers this portable beton batching plant a consistent high grade of evenly mixed material, with its good quality mixing blades, paddles, arms and liners.
3. Highly precise dosing of water, cement, fly-ash, additive
Focus portable beton batching plant dosing is realized by three-point suspension sensors, and they are all metered separately.
4. Optimized and modular design
Installation of Mobile Concrete Mixing Plant in Algeria:
| Model | YHZS25 | YHZS35 | YHZS50/60 | YHZS75 | |
| Output capacity | 25³/h | 35³/h | 50³-60³/h | 75³/h | |
| Overall power | 40kw | 60kw | 85kw | 105kw | |
| Discharge height | 3800mm | ||||
| Max. hauling speed | 40km/h | ||||
| warranty | 13months after commissioning | ||||
| After-sale service | Guidance on erecting, commissioning and operator training, 24/7 technical assistance afterwards | ||||
| Concrete mixer | JS500 | JS750 | JS1000 | JS1500 | |
| Motor power | 18.5kw | 30kw | 18.5kwX2 | 30kwX2 | |
| Max. aggregate dia. | 80mm | ||||
| Aggregate batcher | PLD800 | PLD1200 | PLD1600 | PLD2400 | |
| Aggregate weighing precision | ±2% | ||||
| Aggregate feeder | Belt conveyor | ||||
| Other scale scope | Cement | ±1% | |||
| water | ±1% | ||||
| additive | ±1% | ||||
| Control system | Auto computer control, 1 set | ||||
| Pneumatic system | 1 set | ||||
