2021 New Arrival Wire Rope Pulling Hoist (CD1/MD1)

Product Description

2015 New Arrival Wire Rope Pulling Hoist( CD1/MD1)

=========Product Description===========

01- travelling speed: 20m/min (dual speed 20/6 is optional)

02- Hoist electrics cubicle including low voltage transformer

03- Motor protection IP54 insulation class F

04- Push button box with emergency button

05- Rope guide for use in aggressive environment

06- Remote control is optional, Hook with safety latch

07- hoist is made under the FEM European standard, with planetary gearbox(low noises and free maintenance).

08- The motor and gearbox are installed at the same side, help the hosit
to run smoothly and increase of service life.

==========Specification Details===========

Type	Capacity	Classification	Lifint Standard(M)	Lifing Speed(m/min)	Travelling Speed(m/min)	Rope Reeving	Lifing Motor type power(kw)	Travelling Motor type power(kw)(suspened type)	Protection Class	I-beam Track(mm)	Min Turing Radius	N.W(KG)
CD1 MD1	0.5	M3	6	8 8/0.8	20 20/6.7 30 30/10	2/1.0	ZDY 11-4(0.8) ZDS1-0.2/0.8 (0.2/0.8)	ZDY11-4(0.2)	IP44 IP54	88-124	1	135
			9								1	140
			12								1	155
			18								1.8	175
			24								2.5	185
			30								3.2	195
	1	M3	6	8 8/0.8	20 20/6.7 30 30/10	2/1.0	ZD22-4(1.5) ZDS1-0.2/1.5 (0.2/1.5)	ZDY11-4(0.2)	IP44 IP54	88-124	1	180
			9								1	190
			12								1	205
			18								1.8	220
			24								2.5	235
			30								3.2	235
	2	M3	6	8 8/0.8	20 20/6.7 30 30/10	2/1.0	ZD31-4(3) ZDS1-0.4/3 (0.4/3)	ZDY12-4(0.4)	IP44 IP54	100-152	1.2	250
			9								1.2	265
			12								1.5	300
			18								2	320
			24								2.8	340
			30								3.5	360
	3	M3	6	8 8/0.8	20 20/6.7 30 30/10	2/1.0	ZD32-4(4.5) ZDS1-0.4/4.5 (0.4/4.5)	ZDY12-4(0.4)	IP44 IP54	100-152	1.2	320
			9								1.2	340
			12								1.5	350
			18								2	380
			24								2.8	410
			30								3.5	440
	5	M3	6	8 8/0.8	20 20/6.7 30 30/10	2/1.0	ZD41-4(7.5) ZDS1-0.8/7.5 (0.8/7.5) ZD51-4(13)	ZDY21-4(0.8)	IP44 IP54	116-180	1.5	590
			9								1.5	630
			12								1.5	650
			18								2.5	700
			24								3	750
			30								4	800
	10	M3	6	7 7/0.7	20 20/6.7 30 30/10	4/2.0	ZDS1-1.5/13	2XZDY21-4(0.8)	IP44 IP54	142-180	1.5	820
			9								1.5	875
			12								1.5	960
			18								2.5	1015
			24								3	1090
			30								4	1125
	16	M3	6	3.5 3.5/0.35	20 20/6.7 30 30/10	4/1.0	ZD51-1.5/13 ZDS13-1.5 13/1.5	2XZDY21-4(2X0.8)	IP44 IP54	150-178	3	700
			9								3.5	750
			12								3.8	850
			15								4	850
	20	M3	6	3.5 3.5/0.35	20 20/6.7 30 30/10	4/1.0	ZD51-1.5/13 ZDS13-1.5 13/1.5	2XZDY21-4(2X0.8)	IP44 IP54	158-178	3	720
			9								3.5	770
			12								3.8	870
			15								4	880

==========Packaging & Delivery==========

Packaging Details: Standard Wooden Case or at Your Requirements

Delivery Detail: 25-30 Days after Received Deposit for Container Order

=============Our Services================

1- We can make special sample according to the customer's requirement.

2- We have more than 50 professional technical team, provide best after-sales service

3- Fast delivery time

4- We have CE, TUV and GS certification.

5- Test one by one.
